DJL Tunnel Industrial Freezer/Iqf Freezing Continuous Quick Freezer Of Blast Fast Freezing

Place of Origin : Guangdong, China

Brand Name : DJL

Packaging Details : sea shippment package

Supply Ability : 300 Sets per Year

Price : negotiable

Model Number : DJL-QFL-1618F

Certification : CE,ISO9001

MOQ : 1 set

Payment Terms : T/T

Delivery Time : 45 work days

Voltage : 380V/50Hz

Power : 32kw

Dimension(L*W*H) : 18000*1600mm

Weight : 3900kgs

Cooling Capacity : 2000-2500kgs/hour

Key Selling Points : Automatic

Contact Now

DJL Tunnel Industrial Freezer/Iqf Freezing Continuous Quick Freezer Of Blast Fast Freezing

product description

Ensure the stable and long-life operation of food tree hole bag. Maintain and clean the gate on the side of the equipment to facilitate the cleaning and maintenance of the conveyor belt. It can also be designed as vertical lifting open type, which is easier to maintain. There is a drain at the bottom of the collective to drain the accumulated water in the equipment; Overall long life and low energy consumption design of equipment.

Equipment material:	SUS304 stainless steel
Working temperature:	-150℃~room temperature
Temperature control precision:	±2℃
Temperature uniformity:	±5℃
Cooling rate:	≥20℃/min
Heating rate:	≥5℃/min
Distribution specification:	380V/50HZ

Specification

Model	Tunnel length (mm)	Wire belt width (mm)	Tunnel height (mm)	Power (KW)	freezing capacity (kg/h)
DJL-QFL-1206	6000	1200	1750	10	400-600
DJL-QFL-1209	9000	1200	1750	12	800-1000
DJL-QFL-1212	12000	1200	1750	18	1000-1200
DJL-QFL-1609	9000	1600	1750	15	1000-1200
DJL-QFL-1612	12000	1600	1750	28	1800-2100
DJL-QFL-1618	18000	1600	1750	32	2000-2500
DJL-QFL-1815	15000	1800	1750	28	2000-2500
DJL-QFL-1818	18000	1800	1750	32	2200-2800
DJL-QFL-1824	24000	1800	1750	46	2800-3500

DJL Tunnel Industrial Freezer/Iqf Freezing Continuous Quick Freezer Of Blast Fast Freezing

Liquid nitrogen quick freezing system diagram

1. liquid nitrogen freezing tunnel

2. liquid nitrogen tank

3. tank base

4. exhaust duct

5. exhaust fan

6. liquid nitrogen pipeline

FAQ:

1. What are your main products? In which areas?

Our products are of many types and specifications, such as the cabinet type, box type and tunnel type, etc. These series products have been widely used in many domestic and foreign areas, such as the food processing, mechanical engineering, genetic engineering, precision electronic, medical research, plant conservation, aerospace and rear livestock, etc.

2.What certificate do you have?

Passed the ISO9001 Management System Certification in 2019.

3. How to send the equipment to my country?

By sea, using 20'GP, 40'GP or 45'GP containers, depends on size of the equipment.

4. How much liquid nitrogen will be consumed for freezing foods?

Generally 1:1, that is 1 ton nitrogen for 1 ton food The comsumption rate is 1:1 to 1:1.5, actual consumption depends on the dimension and water content.

5. What is your warranty policy?

One year warranty, life-time maintenance.Components and parts are provided for free within warranty date for replacement.
