Industrial -120 Ultra Low Temperature Blast Iqf Freezer For Durian Quick Freezing

Place of Origin : Guangdong, China

Brand Name : DJL

Certification : ISO9001 , CE

Packaging Details : customized

Supply Ability : 20 sets per year

Price : negotiable

Model Number : DJL-QFL-1612F

MOQ : 1 set

Payment Terms : T/T

Delivery Time : 45 work days

Voltage : 220V/380V 50hz

Dimension(L*W*H) : 12000*1600mm

Weight : 4200kg

After-sales Service Provided : Video technical support and Online support

Cooling Capacity : 100%

Liquid nitrogen freezing temperature : Lowest -150℃, commonly used -120℃

Contact Now

Industrial -120 Ultra Low Temperature Blast Iqf Freezer For Durian Quick Freezing

product description

The tunnel refrigerator uses liquid nitrogen (Lin) as refrigerant to directly freeze food. The conveying speed can be flexibly adjusted according to different products. The equipment is also equipped with automatic belt forgetting tightness adjustment device.

Equipment material:	SUS304 stainless steel
Working temperature:	-150℃~room temperature
Temperature control precision:	±2℃
Temperature uniformity:	±5℃
Cooling rate:	≥20℃/min
Heating rate:	≥5℃/min
Distribution specification:	380V/50HZ

Industrial -120 Ultra Low Temperature Blast Iqf Freezer For Durian Quick Freezing

Specification

Model	Tunnel length (mm)	Wire belt width (mm)	Tunnel height (mm)	Power (KW)	freezing capacity (kg/h)
DJL-QFL-1206	6000	1200	1750	10	400-600
DJL-QFL-1209	9000	1200	1750	12	800-1000
DJL-QFL-1212	12000	1200	1750	18	1000-1200
DJL-QFL-1609	9000	1600	1750	15	1000-1200
DJL-QFL-1612	12000	1600	1750	28	1800-2100
DJL-QFL-1618	18000	1600	1750	32	2000-2500
DJL-QFL-1815	15000	1800	1750	28	2000-2500
DJL-QFL-1818	18000	1800	1750	32	2200-2800
DJL-QFL-1824	24000	1800	1750	46	2800-3500

Our Advantages

1. More than 10 years of professional recognition for ultra-low temperature deep cooling ,own independent intellectual property rights with more than 10 patented technologies.

2. The ability of compound innovation and multi-technology integration makes DJL unique in freezing machine industry.

3. Personalized scheme provides you the best cost performance of product

4. Close cooperative relationships with many universities

5. Three minutes quick-freezing ,the temperature low to minimum -196℃

6. Reasonable &exclusive quick-freezing total solution maximize utilize/save customers cost.

7. Free experiment and verification supporting .

8. Better serving customers by setting up branches and offices in country's areas.

Industrial -120 Ultra Low Temperature Blast Iqf Freezer For Durian Quick Freezing Images
