Blast Chiller Cryogenic Tunnel Freezer Seafood Liquid Nitrogen Tunnel Freezer

Product Categories

Liquid Nitrogen Tunnel Freezer [55]
Blast Tunnel Freezer [24]
Mesh Belt Tunnel Freezer [40]
Spiral Belt Freezer [17]
Cryogenic Freezing Chamber [26]
Liquid Nitrogen Blast Freezer [26]
Impingement Tunnel Freezer [7]
Freezing Cabinet [13]
Cryogenic Furnace [10]
Cryogenic Tunnel Freezer [5]
Cryogenic Valve Experimental Equipment [10]
Multipurpose Furnace [10]

Shenzhen Dejieli Refrigeration Technology Co., Ltd.

Contact Now

Blast Chiller Cryogenic Tunnel Freezer Seafood Liquid Nitrogen Tunnel Freezer

Place of Origin : Guangdong, China

Brand Name : DJL

Certification : ISO9001 ce

Packaging Details : sea shippment package

Supply Ability : 15 Set/Sets per Year

Price : negotiable

Model Number : DJL-QFL-1206

MOQ : 1 set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : 30 working days

Applicable Industries : Food & Beverage Factory, Farms

Warranty of core components : 1 Year

Core Components : PLC

Voltage : 380V

Cooling Capacity : 300-600kgs/hour, customized

structure : side door

Working temperature : -150℃---Room temperature

Temperature control precision : Plus or munus 2℃

Contact Now

Blast Chiller Cryogenic Tunnel Freezer Seafood Liquid Nitrogen Tunnel Freezer

1. Inlet port 2. Outlet port 3. Circulating fan 4. Wirebelt transport system

5. Exhaust emission outlet 6. Cleaning drainage 7. Electrical control cabinet

8. Elevator 9. Adjustable bas

Specification

Model	Tunnel length	Wire belt width	Tunnel height	Power	freezing capacity
Model	(mm)	(mm)	(mm)	(KW)	(kg/h)
DJL-QFL-1206	6000	1200	1750	10	400-600
DJL-QFL-1209	9000	1200	1750	12	800-1000
DJL-QFL-1212	12000	1200	1750	18	1000-1200
DJL-QFL-1609	9000	1600	1750	15	1000-1200
DJL-QFL-1612	12000	1600	1750	28	1800-2100
DJL-QFL-1618	18000	1600	1750	32	2000-2500
DJL-QFL-1815	15000	1800	1750	28	2000-2500
DJL-QFL-1818	18000	1800	1750	32	2200-2800
DJL-QFL-1824	24000	1800	1750	46	2800-3500

FAQ

Q1: What are your main products? In which areas?

A1: Our products are of many types and specifications, such as the cabinet type, box type and tunnel type, etc. These series products have been widely used in many domestic and foreign areas, such as the food processing, mechanical engineering, genetic engineering, precision electronic, medical research, plant conservation, aerospace and rear livestock, etc.

Q2: What certificate do you have?

A2: Passed the ISO9001 Management System Certification in 2019.

Q3: How to send the equipment to my country?

A3: By sea, using 20'GP, 40'GP or 45'GP containers, depends on size of the equipment.

Q4: How much liquid nitrogen will be consumed for freezing foods?

A4: Generally 1:1, that is 1 ton nitrogen for 1 ton food The comsumption rate is 1:1 to 1:1.5, actual consumption depends on the dimension and water content.

Q5: What is your warranty policy?

A5: One year warranty, life-time maintenance.Components and parts are provided for free within warranty date for replacement.
